Features:

• Description: Axial Flow Rotary Muffin Cooling Fan 80x80x25mm Top Motor DF1208SM DC12V 0.20A 2.4W Molex IDE 4-Pin Male Female Pass-Thru 15-inch Power DC 2.54mm Pitch 3-Pin 1-Conductor 15-inch Sensor UV Reactive Color Blue Frame Blue Impeller Blades SKU 190324
• Manufacturer: Dynaeon Industrial Co., Ltd. (the parent manufacturing arm)
• Brand and Distributor:
  • Top Motor (the product line)
  • Dynaeon Industrial Co., Ltd.
  • Dynatron Corp. (the global brand)
• Model: (and / or Compatible / Equivalent)
  • DF1208SM UV Reactive
  • DF128025SM UV Reactive
• Brief Spec.:
  • Design: DC Brushless Cooling Fan
  • Fan Size: 80x80x25mm
  • Power Rating: DC12V 0.20A 2.4W
  • Bearing: Sleeve Bearing
  • Speed: 2600 RPM
  • Air Flow: 31.3 CFM
  • Noise Level: 31.8 dBA
  • Material: UV-Reactive Polycarbonate, PBT (Polybutylene Terephthalate) Blend
  • Connection:
    • Molex Compatible IDE 4-Pin Male Female Pass-Thru Connector 15-inch Power Wire
    • DC 2.54mm Pitch 3-Pin 1-Conductor Connector 15-inch Sensor Wire
• Weight: 3.1 oz (estimated shipping weight 7 oz)
• Condition: (Subject to Availability)
  • SKU ______A - Aged Open Box, not been used, with signs of cosmetic wear.
  • SKU ______N - New
  • SKU ______B - Bulk New, seller repackaged.
  • SKU ______E - Excess Inventory, not been used, may have signs of age.
  • SKU ______P - For Parts, Condition Vary, Not Eligible for Return or Refund.
  • SKU ______O - Open Box, unused, may have signs of cosmetic wear.
  • SKU ______R - Refurbished to working condition.
  • SKU ______U - Used, (Condition Vary), may have (or with) signs of cosmetic wear.
• Packaging: Non-Retail Packaging, in Unprinted Box or Plastic Bag.
• For use with or saved from: (for reference only)
  • The DF1208SM and DF128025SM are actually different part numbers for the exact same 80mm cooling fan manufactured by Dynatron / Top Motor. The UV Reactive line is a specialty Ultraviolet Fluorescent variant of Dynaeon Industrial's classic 80mm cooling fan line popular during the height of custom PC case modding fluoresce brightly under a cold cathode UV light or UV LEDs.
    • DF1208SM
      • 'DF' Direct Current (DC) Fan
      • '12' 12V DC nominal operating voltage.
      • '08' frame width and height 80mm x 80mm, 25mm thickness
      • "S' Sleeve Bearing System
      • 'M' Medium Speed / Medium Output performance tier 2600 RPM.on (PWM) duty cycle reductions and are meant to run primarily at fixed voltages.
    • DF128025SM
      • 'DF' Direct Current (DC) Fan
      • '12' 12V DC nominal operating voltage.
      • '80' frame width and height 80mm x 80mm.
      • '25' frame thickness / depth code 25mm thick.
      • "S' Sleeve Bearing System
      • 'M' Medium Speed / Medium Output performance tier 2600 RPM.on (PWM) duty cycle reductions and are meant to run primarily at fixed voltages.
  • Serial Number Available or Sold:
    • SN 0089884 New
