Features:

• Description: Axial Flow Rotary Muffin Cooling Fan 80x80x25mm Top Motor DF1208SM Dynaeon Industrial DC12V 0.20A 2.4W Molex Compatible IDE 4-Pin Power Male to Female 19-inch + 3-inch Wire SKU 211220
• Manufacturer: Dynaeon Industrial Co., Ltd. (the parent manufacturing arm)
• Brand and Distributor:
  • Dynatron Corp. (the global brand)
  • Top Motor (the product line)
• Model: (Compatible, Equivalent, & Interchangeable)
  • DF1208SM
  • DF128025SM
• Brief Spec.:
  • Design: DC Brushless Fan
  • Fan Size: 80x80x25mm
  • Power Rating: DC12V 0.20A 2.4W
  • Bearing: Sleeve Bearing
  • Speed: 2600~2700 RPM
  • Air Flow: 27.94~37 CFM
  • Noise Level: 30.1 dB(A)
  • Material: PBT Thermoplastic Polybutylene Terephthalate UL 94V-0 Rated
    • Frame Housing: PBT Thermoplastic Polybutylene Terephthalate UL 94V-0 Rated
    • Impeller Blades: PBT Thermoplastic Polybutylene Terephthalate UL 94V-0 Rated
  • Connection: Molex Compatible IDE 4-Pin Power Male to Female
  • Overall Wire Length: 22-inch
    • 19-inch: from Fan to 4-pin Male Connector
    • 3-inch: from 4-pin Male Connector to 4-pin Female Connector
  • Photos are representative of the model and specifications you will receive; however, the exact factory batch codes, manufacturing dates, and plant location stamps may differ across individual units.
• Weight: 2.6 oz (estimated shipping weight 7 oz)
• Condition: (Subject to Availability)
  • SKU ______A - Aged Open Box, not been used, with signs of cosmetic wear.
  • SKU ______N - New
  • SKU ______B - Bulk New, seller repackaged.
  • SKU ______E - Excess Inventory, not been used, may have signs of age.
  • SKU ______P - For Parts, Condition Vary, Not Eligible for Return or Refund.
  • SKU ______O - Open Box, Unused, originally bulk in master carton, seller repackaged.
  • SKU ______R - Refurbished to working condition.
  • SKU ______U - Used, (Condition Vary), (may have or with) signs of cosmetic wear.
• Package: Non-Retail Packaging, in Unprinted Reused Box and Plastic Bag.
• For used with or pulled from: (for reference only)
  • The Top Motor DF1208SM and DF120825SM are the exact same 80mm cooling fan designed as a quiet, mid-tier 12V DC cooling fan. It balances steady airflow with low noise levels, making it ideal for standard desktop computers and enclosed electronics. Top Motor (a manufacturing brand of Dynaeon Industrial / Dynatron) used two different part number naming schemes over the years for the same physical component.
  • DF1208SM Part Number Breakdown:
    • 'D' DC (Direct Current)
    • 'F' Fan
    • '12' 12V DC operating voltage.
    • '08' 80mm width × 80mm height x 25mm thickness.
    • 'S' Internal Mechanical Format Sleeve Bearing system.
    • 'M' Factory Tuning Category Medium Speed output tier.
  • Serial Number Available or Sold:
    • SN 0082971~0083070 New
